MR-6400a
Analog Input - Industrial Remote Control Module
● 4-channel analog input module
● Isolated current input type
● High resolution: 24-bit ADC
● 150 mA overcurrent protection
● Wide current input range: ±0-20 mA
● High current accuracy: ±0.015% FSR
● Supports LED output indicator
● Wide operating temperature range: -25°C to +75°C
● Supports Modbus RTU protocol
The MR-6400a is an analog input module that provides 4 isolated input channels. The input type is current input. These channels are available for the same input range. The module also features 2,500 VDC intra-module isolation, as well as 150 mA overcurrent protection for current input. The MR-6400a supports up to ±20 mA bi-direction current input, and it also supports the Modbus RTU protocol.
- Building Automation
- Factory Automation
- Machine Automation
- Testing Equipment
- Remote Maintenance
- Remote Diagnosis
